Applications
Semiconductor, Biotech, Pharmaceutical
Technical Drawings
To request GA- and/or 3D- drawings (.step) please contact sale@dialoguetoolkit.com.
Downloads
Features
- Metal to metal diaphragm seal
- Low particle entrapment
- 100% helium leak tested
- 10 Ra or 5 Ra microinch internal surface
Specifications
- Maximum Operating Pressure:
3000 psig(210 barg) @ 100℉(38℃) - Operating Temperature Range:
-10℉(-23℃) to 150℉(65℃)
